Power Supply: Center Tip Polarity: Positive
Input Current: 0.5A
Input Voltage: 100 ~ 240 AC
Output Current: 1.5A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
Specification: Hardware
Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: No
Output Signal: HDMI
Ports: 1
Performance
Maximum Cable Length: 0.2 ft. [0.1m]
Wide Screen Supported: Yes
Connector(s)
Connector A:
- 1 x HDMI (19 pin) Latching Female
- 1 x RJ-45 Female
Connector B:
- 1 x HDMI (19 pin) Female
- 1 x RJ-45 Female
Environmental
Humidity: 0% - 80 % RH (non-condensing)
Feature: Extend video where power outlets are limited with power over cable that powers...
Power Supply: Power Adapter Included: Yes
Output Voltage: 9 DC
Output Current: 0.6A
Center Tip Polarity: Positive
Specification: Cabling: Cat 5e UTP or better
Daisy-Chain: No
Local Unit Connectors
1 - RJ-45 Female
1 - VGA (15 pin; High Density D-Sub) Male
2 - 3.5 mm Mini-Jack (3 Position) Female
2 - VGA (15 pin; High Density D-Sub) Female
Remote Unit Connectors
1 - RJ-45 Female
2 - 3.5 mm Mini-Jack (3 Position) Female
2 - VGA (15 pin; High Density D-Sub) Female
Maximum Cable Length: 500 ft [152.4 m]
Color: Black
Enclosure Type: Aluminum
Feature: Extend and distribute a VGA signal and the accompanying audio to a remote display over Cat5 cable - vg...
Distance: Maximum Distances - (1080i only)
CAT5E (stranded) - 40m (130 ft.)
CAT5E (solid) - 50m (165 ft.)
CAT6 (stranded or solid) - 50m (165 ft.)
Max Distance: 50m / 165 ft.
Resolution Support: Maximum Digital Resolutions: 1080p / 1920x1080
Supported Resolutions:
1080i
- Cat6 (stranded or solid) - up to 50m
- Cat5e (solid) - up to 50m
- Cat5e (stranded) - up to 40m
1080p
- Cat6 (solid or stranded) - up to 40m
- Cat5 (solid) - up to 20m
- Cat5 (stranded) - up to 16m
See product manual for further details
HDMI: Local Unit Connectors:
1 x HDMI (19-pin) Female
Remote Unit Connectors:
1 x HDMI (19-pin) Female
Network Interface: Local Unit Connectors:
2 x RJ-45 Female
Remote Unit Connectors:
2 x RJ-45 Female
Network Interface: USER INTERFACE:
Indicator LEDs: Outputs, inputs, communication link and power
Controls: EDID setup button, 12 setup DIP switches
1 RS-232: On a Mini–USB female connector for firmware upgrade
S-Video: VIDEO:
Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
Max. Resolution: Up to 4K@60Hz (4:2:0) 24bpp
Standards Compliance: Supports HDCP 1.4 and HDBaseT 1.0
HDMI Support: Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
Other Connector: INPUTS:
1 HDMI: On an HDMI female connector
OUTPUTS:
2 HDBT: On RJ–45 female connectors
1 Loop HDMI: On an HDMI female connector
PORTS:
1 IR: On a 3.5mm mini jack for IR link extension
1 RS-232: On a 3–pin terminal ...
Resolution Support: 480p/720p/1080p at 60 Hz; 1920 x 1200 and 1600 x 1200 at 60 Hz
Video Bit Rate/Bandwidth: 340 MHz (10.2 Gbps)
Power Consumption: 20W
Power Supply: AC input: 100-240 VAC, 50-60 Hz, 0.8 A
Output: 5-VDC, 2 A
Specification: Audio Support: Stereo 2-channel analog audio
RoHS: Yes
Connectors: Transmitter: 1 x DVI-D F input, 1 x DB9 F (RS-232), 1 x 3.5-mm input jack (stereo audio), 1 x RJ-45 (CATx interconnect)
Receiver: 1 x DVI-D F output, 1 x DB9 M (RS-232), 1 x 3.5-mm output jack (stereo audio), 1 x RJ-45 (CATx interconnect)
Indicators: 2 x LEDS on both the transmitter and receiver: 1 x Power, 1 x Link
Feature: Use a single CAT5e/6/7 run for extending DVI-D video plus audio.
Also extends RS-232 and HDCP signals to the remote screen.
Goes much farther than standa...
Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
System Requirements: Computer with DVI video card, and monitor with DVI input
Specification: Cable Type: DVI
Display Style: Extender
Connector A: DVI-D SINGLE LINK (MALE)
Connector B: X2) RJ45 (FEMALE)
Connector C: DVI-I (FEMALE)
System Requirements: Resolution may vary at distances depending on cable quality. Cat 5e UTP cables are recommended.
Power Supply: Power Adapter Included: Yes
Output Voltage: 12 DC
Output Current: 0.6A
Center Tip Polarity: Positive
Specification: Cabling: Cat 5 UTP
Audio: No
Daisy-Chain: No
Color: Black
Enclosure Type: Aluminum
Local Unit Connectors
1 - RJ-45 Female
1 - VGA (15 pin; High Density D-Sub) Female
Remote Unit Connectors
1 - RJ-45 Female
1 - VGA (15 pin; High Density D-Sub) Female
Feature: Extends video signal by up to 250 ft. (80m)
Supports 1920x1200 or 1600x1200 resolutions at 150 ft. (50m)
Supports 1280x1024 or 1024x768 resolutions at 2...
Feature: Extends HDMI signals with stereo audio to a remote display over UTP CAT5e/6 cabling up to 120 meters
Works as a scalable TX/RX Matrix over dedicated IP network, allows up to 256 total units, limited to 100 transmitters. Additional transmitter units (part# CE-H23B11-S2) and receiver units (part# CE-H23C11-S2) sold separately
Supports up to 1080p @60Hz video resolution to deliver stunning and crystal clear images
Supports IR pass back function to control the source device from RX location
Supports computer control software to select and switch between source devices (Matrix only)
Supports HDbit-T protocol with H.264 compression over IP
HDMI output on the transmitte...
Color: Supports 24-bit True Color (8-bits per channel)
HDMI: Connector B: (X2) HDMI (FEMALE)
Other Connector: Connector A: (X4) RJ45 (FEMALE)
Specification: Cable Type: HDMI
Display Style: Splitter
Color: Black
Feature: 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N202-Series, is required to achieve maximum distance and resolution.
Use Tripp Lite P568-Series HDMI cables to connect to HDMI source and monitor.
Extends a 1080p (60Hz) signal up to 150 ft. when used with a B126-1A0 or B126-1A0-WP-1 active remote receiver unit.
Extends a 1080p (60Hz) signal up to 50 ft. when used with a B126-1P0 or B126-1P0-WP passive remote receiver unit.
Extends a 3D signal up to 125 ft. when used with an active remo...
