Specifications: Output
Output Power Capacity: 3200 Watts / 4000 VA
Max Configurable Power: 3200 Watts / 4000 VA
Nominal Output Voltage:120V,208V
Output Voltage Note: Configurable for 120/208 or 120/240 output voltage
Output Voltage Distortion: Less than 5% at full load
Output Frequency (sync to mains): 47 - 63 Hz
Waveform Type: Sine wave
Output Connections: (1) Hard Wire 4-wire (2PH + N +G)
Input
Nominal Input Voltage: 200V,208V
Input Frequency: 45 - 65 Hz (auto sensing)
Input voltage range for main operations: 155 - 276V
Other Input Voltages: 240V
Specifications: Load Rating: 20 amps @ 120 volts
Maximum Load Inrush Energy: 1400 Joules total during power-up
UL 1449 Adjunct Classification Test Results: 1000 surges, 6000 volts, 3000 amps, B3 pulse; Measured suppressed voltage: 170 volts; no failures
Federal Guidelines: Grade A, Class 1, Mode 1(CID A-A-55818)
EMI/RFI Filter, Normal Mode (50-ohm load): > 30 dB 100 KHz - 50 MHz
EMI/RFI Filter, Common Mode (50-ohm load): > 20 dB 1 MHz - 50 MHz
Under-Voltage Auto Shutdown: Adjustable from 90V to 110V
Over-Voltage Auto Shutdown: Adjustable from 130V to 150V
Endurance (C62.41-1991 Category B3 pulses): 1 kV>500,000; 3 kV>10,000; 6 kV>1000
Control Inputs: Momentary Switch, Latching Switch,Contact Closure or 5-30 Vdc
Input Control Current: 3 mA
DC Voltage Output: 12 Vdc, 40 mA maximum load
Auxiliary Relay Cont...
Specifications: Plug/Connector Type: Hardwired
Receptacles: Hardwired, 3 x NEMA L6-30R
Form Factor: 3U Rack-mountable
Load Capacity: 11 kVA
Input Voltage: 208 V AC
