Specifications: Hardware Version: 2
Interface:
"Data" Input Ports: 4 x RJ-45
"Data+Power" Output Ports: 4 x RJ-45
Data Rate: 10/100/1000 Mbps
LED:
System: Power x 1 (Green)
Per PoE Port: PoE ready / in-use x 4 (Green)
Network Cable:
10Base-T: 4-Pair UTP Cat. 5 up to 100m (328 ft.)
100Base-TX: 4-Pair UTP Cat. 5 up to 100m (328 ft.)
1000Base-T: 4-Pair UTP Cat. 5e, 6, up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m, 328 ft.)
Power Requirements: DC 52V~56V
PoE Power Supply Type: Mid-Span
PoE Power Output: Per Port DC 52V 30.8 watts / 15.4 watts
Power Pin Assignment: 4/5(+), 7/8(-)
PoE Power Budget: 120 watts
Number of 802.3af PD Class 0, 1, 2, 3 can be powered: 4
Number of 802.3at PD Class 1, 2, 3 can be powered: 4
Number of 802.3at PD Class 0, 4 can be powered: 4
Standards Compliance:
IEEE 802.3 10Bas...
Specifications: Interface:
PoE (Power + Data) Input Port: 1 x RJ-45 STP
Data” Output Port: 1 x RJ-45 STP
DC Out Plug Connector: 1
LED Indicator System: PoE In x 1 (Green)
Network Cable:
10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: 2-Pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA / TIA-568 100-ohm STP (100m)
Data Rate: 10/100/1000 Mbps (varies on Ethernet device attached)
DIP Switch: 12V DC / 24V DC output voltage
Power Input: 802.3at PoE+ 52 ~ 56V DC
PoE Standard: IEEE 802.3at High Power over Ethernet
Number of clients device can be powered: 1
Power Output:
12V DC, 2A max
24V DC, 1A max
Standards Compliance:
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3at...
Specifications: What's in the box:
Digi Connect EZ 2 - serial server, 2-port, with accessories
Power supply - 12 V, 3 A (24000136)
DIN rail clip (76002095)
Specifications: Interface: LAN:
1 x RJ-45 STP, "Data" Input Port
POE: 1 x RJ-45 STP, "Data + Power" Output Port
AC Connector: 1 x AC Input power socket, IEC-320 C6
Network Cable:
Ultra PoE (60W): 4-pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
802.3af / at PoE(15W / 30W): 2-pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
LED Indicator:
System: Power x 1 (Green)
PoE Port: Active, PoE ready / In Use x 1 (Green)
Data Rate: 10/100/1000 Mbps
Unit Output Voltage: DC 50-57V, 1.2A
Power Requirements: 100-240V AC @ 50/60 Hz, 1.5A max.
Power Consumption: 60 watts max.
PoE Standard:
Ultra PoE over 4-pairs UTP,
High Power over Ethernet End-Span / Mid-Span PSE
PoE Power Supply Type: End-Span + Mid-Span
Power Pin Assignment:
Pair 1 End-Span: 1/2 (+), 3/6 (-)
Pair 2 Mid-Span: 4/5 (+), 7/8 (-)
PoE Power Output:
DC 50-57V/60-w...
Specifications: Interface:
"Data" Input Ports: 16 x RJ45
"Data + Power" Output Ports: 16 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000Mbps
LED
System: SYS PWR x 1 (Green), PoE Failure x 1 (Red), Fan Failure x 2 (Red)
Management port x 2: 1000 (Green), 10/100(Orange)
Per PoE Port: Ultra 60W PoE-in-use x 1 (Green), 802.3at/af PoE-in-use x1 (Orange), PoE Power Usage LED x4 (Green)
Power Requirements: 100 - 240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts (max.) / 2729BTU
Ventilation: Fan x 3
Enclosure: Metal
PoE Standard:
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
4-pair Ultra PoE
PoE Power Supply Type: End-span / Mid-span / UPoE (Ultra PoE)
Power Pin Assignment:
Pair 1 end-span: 1/2(-), 3/6(+)
Pair 2 mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),...
Specifications: Ethernet Interface:
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both Mid-span and End-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACTESD Protection: 4 KV DC
EFT Protection: 2 KV
Enclosure Metal: case
Installation: Wall mount or DIN rail with optional kit
Power Requirements:
RJ45 PoE Input: 802.3at/af 48~56V DC
DC Input: 48~56V DCStandards Compliance:
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Specifications: Interface:
"PoE (Power + Data)" Input Port : 1 x RJ-45 10/100/1000Base-T
"Data" Out Port: 1 x RJ-45 10/100/1000Base-T
DC Out Plug Connector: 1 removable 4-Pin terminal block
LED Indicator:
System: Power Ready x 1 (Green)
Network Cable:
10/100/1000Base-T: 4-Pair UTP Cat. 5, 5e, 6
Distance up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000 Mbps (vary on Ethernet device attached)
DIP Switch: 12V DC / 24V DC output voltage
Power Input: 802.3at PoE 48~56V DC
Power Output: 12V / 24V DC, max 2A (adjustable)
Enclosure: IP30 metal case
Installation: DIN rail kit and wall mount ear
ESD / EFT Protection: 6 KV DC
PoE Standard: IEEE 802.3at High Power over Ethernet
Number of devices that can be powered: 1 or 2 (Vary on device's power requirement; DC1 + DC2 cannot be over 25 watts.)
...
