Specifications: xDirect232 Single Port RS232 10/100 Device Server
Serial Connectors: Single-port: DB9F RS232 (DCE Pinned)
Ethernet Interface: 10/100M RJ-45
Serial Interface Baud Rate: 300bps to 921.6 Kbps
LED Indicators: Power/Status, Link, Activity, Serial RX Activity & TX Activity
CPU: Based on DSTni-EX Enhanced 16-bit x86 Architecture
Memory: 256 KB SRAM, 1 MB Flash
100-240 VAC International Power Supply with Regional Adapters.
Specifications: Interface:
"Data" Input Ports: 16 x RJ45
"Data + Power" Output Ports: 16 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000Mbps
LED
System: SYS PWR x 1 (Green), PoE Failure x 1 (Red), Fan Failure x 2 (Red)
Management port x 2: 1000 (Green), 10/100(Orange)
Per PoE Port: Ultra 60W PoE-in-use x 1 (Green), 802.3at/af PoE-in-use x1 (Orange), PoE Power Usage LED x4 (Green)
Power Requirements: 100 - 240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts (max.) / 2729BTU
Ventilation: Fan x 3
Enclosure: Metal
PoE Standard:
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
4-pair Ultra PoE
PoE Power Supply Type: End-span / Mid-span / UPoE (Ultra PoE)
Power Pin Assignment:
Pair 1 end-span: 1/2(-), 3/6(+)
Pair 2 mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),...
Specifications: Safety
IEC 60950-1, EN 60950-1, CB Certificate/Report, UL/CSA 60950-1
EMC
CC / ICES-003 Emission (USA/Canada)
CRISP 22 Emission (International)
EN61000-4-2 Electrostatic Discharge
EN61000-4-3 Radiated RFI Immunity
EN61000-4-4 Electrical Fast Transients level 4
EN61000-4-5 Electrical Surge Level
EN61000-4-6 RF Conducted
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
Specifications: Standards
802.3 10BaseT
802.3u 100BaseT
802.3ab Gigabit Ethernet
Proprietary PoE
Physical Interface
1) Gigabit Data Port
(1) Gigabit Data & Power Output Port
(1) IEC-320 C6 AC Connector
Power
Input voltage : 100 to 240 VAC
Input current: 0.8A maximum for 100 VAC
AC input Frequency: 47-63Hz
Maximum output power: 32.8W
Pin4, 5:54V; Pin7, 8: Return
Temperature Range
Operating: 32 degree F to 104 degree F (0 degree C to 40 degree C)
Storage: -22 degree F to 176 degree F (-30 degree C to 80 degree C)
Humidity (non-condensing)
Operating: 5 to 90% or less
Storage: 5 to 90% or less
LED Indicator: 1 x Power on Green
Mounting: Wall (anchors & screws included)
Dimensions: 1.30" x 3.90" x 2.27"
Parts: Manufacturers Limited Warranty: 1 Year / Parts Only
Specifications: Interfaces:
PoE IN:1 x 10/100/1000BASE-T Ethernet with IEEE 802.3at PoE "Data + DC power" in auto MDI/MDI-X, auto-negotiation RJ45 connector
PoE OUT: 2 x 10/100/1000BASE-T Ethernet with IEEE 802.3at/802.3af PoE "Data + DC power" out auto MDI/MDI-X, auto-negotiation RJ45 connector
Power over Ethernet
PoE Standard:
"PoE In" Port: IEEE 802.3at Power over Ethernet Plus end-span/mid-span PD class 4 PD
Per "PoE Out" Port:
IEEE 802.3at Power over Ethernet Plus end-span PSE
IEEE 802.3af Power over Ethernet end-span PSE
PoE Power Supply Type: End-span (Type A)
PoE Power:
"PoE In" Port: 52 - 56V DC, max. 30.8 watts
Per "PoE Out" Port: 44 - 55V DC, max. 25 watts
Power Pin Assignment:
"PoE In" Port: 1/2 (+), 3/6 (-); 4/5 (+), 7/8 (-)
Per "PoE Out" Port: 1/2 (+), 3/6 (-)
Data Rate: 10/100/1000Mbps
MAC Address Table: 2K
Data Bu...
Specifications: Kit Content:
1 x Country-specific power cord, IEC, 6 ft.
1 x Power adapter
Input: 100 - 240V AC, 50/60Hz 0.6A
Output: 12V DC 2.0A
AC plug: country-specific
DC plug: Right-angle, 2.5 x 5.5 x 10 mm (ID x OD x L) female, positive center
DC cable length 1.5m
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate...
Specifications: Network Technology: 1000Base-TX, 1000Base-T
Power Description Plug/Connector Type: Terminal Block (3 Wire), Type N
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1
Total Number of Expansion Slots: 1.0
Network (RJ-45): Yes
Number of PoE (RJ-45) Ports: 1
Total Number of Ports: 1
Media Type Supported: Twisted Pair
Fiber Mode Supported: Optical Fiber, Single-mode, Multi-mode
Weight (Approximate) 2.80 oz
Height 1.9", Width 1.4", Depth 2.3"
Environmental Compliance: Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate):
5.40 oz
...
Specifications: Interface:
"Data" Input Port: 1 x RJ-45 STP
"PoE (Data+Power)" Output Port: 1 x RJ-45 STP
Input power terminal block: 1
LED Indicator:
System: Power 1, Power 2, Fault (Green)
PoE Port: PoE in Use x 1 (Green)
Network Cable:
10Base-T: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000Mbps
Dimension: 1.26" x 5.31" x 3.46"
Weight: 1.05 lbs.
Unit Input Voltage: 24 - 48V DC; 24V AC
Power Consumption: 30 watts max.
Number of device can be powered: 1
Installation: DIN rail kit and wall mount ear
Alarm:
Provides one relay output for power failure,
Alarm relay current carry ability: 3A at DC 30V
Enclosure: IP30 slim type metal case
Power over Ethernet
PoE Standard: IEEE 802.3at High ...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Single-mode
Fiber Optic Cable Wavelength:
0.1 mil
Maximum Distance Supported:
40 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of LC Ports:
1
LC Port Type:
Duplex
Number of Network (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Fiber Optic Cable Wavelength:
0 mil
Maximum Distance Supported:
0.55 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
Color ...
