Specifications: Interface:
"Data" Input Port: 1 x RJ-45 STP
"PoE (Data+Power)" Output Port: 1 x RJ-45 STP
Input power terminal block: 1
LED Indicator:
System: Power 1, Power 2, Fault (Green)
PoE Port: PoE in Use x 1 (Green)
Network Cable:
10Base-T: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
100Base-TX: UTP Cat. 3, 4, 5, up to 100m (328 ft.)
1000Base-T: UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate: 10/100/1000Mbps
Dimension: 1.26" x 5.31" x 3.46"
Weight: 1.05 lbs.
Unit Input Voltage: 24 - 48V DC; 24V AC
Power Consumption: 30 watts max.
Number of device can be powered: 1
Installation: DIN rail kit and wall mount ear
Alarm:
Provides one relay output for power failure,
Alarm relay current carry ability: 3A at DC 30V
Enclosure: IP30 slim type metal case
Power over Ethernet
PoE Standard: IEEE 802.3at High ...
Specifications: 10/100/1000BASE-T (RJ-45) [100 m/328 ft.] to 1000BASE-SX 850nm multimode (SC) [62.5/125 µm fiber: 220 m/722 ft.]
Link Budget: 7.0 dB [50/125 µm fiber: 550 m/1804 ft.]
Standards: IEEE 802.3
Max Frame Size: untagged: 1632 bytes / tagged: 1628 bytes
Status LEDs:
PWR (Power): (below RJ-45)
ON = Lit for normal operation
FX-Link/Act (Fiber Link/Activity):
(Upper Left on RJ-45)
ON = Link; Flashing = Activity
TX-Link/Act (Copper Link/Activity):
(Upper Right on RJ-45)
ON = Link; Flashing = Activity
Power
Consumption: 3.15 Watts
Sources: Unit accepts 5 VDC to 28 VDC
Wall Mount AC adapter: 12 VDC 400mA
Environment
Storage: -15 to +65 °C
Operating: 0°C to 50°C
Altitude: 0 – 10,000 feet
Humidity: 5% to 95% (non-condensing)
Compliance
Safety: Wall Mount Power Supply, UL Listed,
C-UL Listed ...
Specifications: Interfaces/Ports
Total Number of Ports:
2
Network (RJ-45):
Yes
DVI:
No
USB:
No
Parallel Port:
No
Digital Audio:
No
Digital Audio/Video:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of SC Ports:
1
SC Port Type:
Duplex
Media & Performance
Media Type Supported:
Twisted Pair
Optical Fiber
Fiber Mode Supported:
Single-mode
Fiber Optic Cable Wavelength:
0.1 mil
Maximum Distance Supported:
40 km
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
1000Base-SX/ LX
Power Description
Power Source:
AC Adapter
Input Voltage:
12 V DC
Power Consumption:
4 W
Plug/Connector Type:
Type M
Physical Characteristics
...
Specifications: Ethernet Interface:
Copper: 10/100BASE-TX RJ45, auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PD (Powered Device)
PoE Input: Supports both mid-span and end-span PSE
Input Range: 48~56V DC
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100m
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE IN
LNK / ACTESD Protection: 4 KV DC
EFT Protection: 2 KV
Enclosure Metal: case
Installation: Wall mount or DIN rail with optional kit
Power Requirements:
RJ45 PoE Input: 802.3at/af 48~56V DC
DC Input: 48~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet (802.3at Type 2)
Specifications: Interface: LAN:
1 x RJ-45 STP, "Data" Input Port
POE: 1 x RJ-45 STP, "Data + Power" Output Port
AC Connector: 1 x AC Input power socket, IEC-320 C6
Network Cable:
Ultra PoE (60W): 4-pair UTP Cat. 5, 5e, 6 up to 100m (328 ft.)
802.3af / at PoE(15W / 30W): 2-pair UTP Cat. 3, 4, 5, up to 100m (328 ft.)
LED Indicator:
System: Power x 1 (Green)
PoE Port: Active, PoE ready / In Use x 1 (Green)
Data Rate: 10/100/1000 Mbps
Unit Output Voltage: DC 50-57V, 1.2A
Power Requirements: 100-240V AC @ 50/60 Hz, 1.5A max.
Power Consumption: 60 watts max.
PoE Standard:
Ultra PoE over 4-pairs UTP,
High Power over Ethernet End-Span / Mid-Span PSE
PoE Power Supply Type: End-Span + Mid-Span
Power Pin Assignment:
Pair 1 End-Span: 1/2 (+), 3/6 (-)
Pair 2 Mid-Span: 4/5 (+), 7/8 (-)
PoE Power Output:
DC 50-57V/60-w...
Specifications: Ethernet Interface:
Copper:
10/100BASE-TX RJ45
auto-negotiation / auto-MDI / MDI-X
Power over Ethernet Standard: IEEE 802.3at/af PoE PSE (Power Source Equipment)
PoE Output: 56V DC, 600mA max.
PoE Budget: Up to 25 watts
PoE Mode: End-span, RJ45 Pin 1/2 (+), 3/6 (-)
Data Rate: 100/100 Mbps
Cabling: Cat5e or above
Maximum Distance: 100 meters
Maximum Frame Size: 1522 bytes
LED Indicators:
4 x LEDs
PWR
LRP LNK
PoE-in-use
LNK / ACT
ESD Protection: 4KV DC
Enclosure: Metal case
Installation: Wall mount or DIN rail with optional kit
Power Requirements: BNC Power over Coaxial Input: 44~56V DC
Standards Compliance:
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3af Power over Ethernet (802.3at Type 1)
IEEE 802.3at Power over Ethernet Plus(802.3at Type 2)
Specifications: Interfaces:
PoE IN:1 x 10/100/1000BASE-T Ethernet with IEEE 802.3at PoE "Data + DC power" in auto MDI/MDI-X, auto-negotiation RJ45 connector
PoE OUT: 2 x 10/100/1000BASE-T Ethernet with IEEE 802.3at/802.3af PoE "Data + DC power" out auto MDI/MDI-X, auto-negotiation RJ45 connector
Power over Ethernet
PoE Standard:
"PoE In" Port: IEEE 802.3at Power over Ethernet Plus end-span/mid-span PD class 4 PD
Per "PoE Out" Port:
IEEE 802.3at Power over Ethernet Plus end-span PSE
IEEE 802.3af Power over Ethernet end-span PSE
PoE Power Supply Type: End-span (Type A)
PoE Power:
"PoE In" Port: 52 - 56V DC, max. 30.8 watts
Per "PoE Out" Port: 44 - 55V DC, max. 25 watts
Power Pin Assignment:
"PoE In" Port: 1/2 (+), 3/6 (-); 4/5 (+), 7/8 (-)
Per "PoE Out" Port: 1/2 (+), 3/6 (-)
Data Rate: 10/100/1000Mbps
MAC Address Table: 2K
Data Bu...
Specifications: Interface:
"Data" Input Ports: 16 x RJ45
"Data + Power" Output Ports: 16 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate: 10/100/1000Mbps
LED
System: SYS PWR x 1 (Green), PoE Failure x 1 (Red), Fan Failure x 2 (Red)
Management port x 2: 1000 (Green), 10/100(Orange)
Per PoE Port: Ultra 60W PoE-in-use x 1 (Green), 802.3at/af PoE-in-use x1 (Orange), PoE Power Usage LED x4 (Green)
Power Requirements: 100 - 240V AC, 50/60 Hz, 8A
Power Consumption: 800 watts (max.) / 2729BTU
Ventilation: Fan x 3
Enclosure: Metal
PoE Standard:
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
4-pair Ultra PoE
PoE Power Supply Type: End-span / Mid-span / UPoE (Ultra PoE)
Power Pin Assignment:
Pair 1 end-span: 1/2(-), 3/6(+)
Pair 2 mid-span: 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+),...
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate...
Specifications: Interfaces/Ports
Total Number of Ports:
1
Network (RJ-45):
Yes
Number of PoE (RJ-45) Ports:
1
Media & Performance
Media Type Supported:
Optical Fiber
Twisted Pair
Fiber Mode Supported:
Multi-mode
Single-mode
I/ O Expansions
Total Number of Expansion Slots:
1
Expansion Slot Type:
SFP (mini-GBIC)
Number of SFP Slots:
1
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
1000Base-TX
100Base-TX
100Base-T
Power Description
Power Source:
PoE+
Power Consumption:
60 W
Plug/Connector Type:
Terminal Block (3 Wire)
Type N
Physical Characteristics
Form Factor:
DIN Rail Mountable
Wall Mountable
Height:
1.3"
Width:
3.2"
Depth:
4.1"
Weight (Approximate):
5.40 oz
...
Specifications: Network Technology: 1000Base-TX, 1000Base-T
Power Description Plug/Connector Type: Terminal Block (3 Wire), Type N
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1
Total Number of Expansion Slots: 1.0
Network (RJ-45): Yes
Number of PoE (RJ-45) Ports: 1
Total Number of Ports: 1
Media Type Supported: Twisted Pair
Fiber Mode Supported: Optical Fiber, Single-mode, Multi-mode
Weight (Approximate) 2.80 oz
Height 1.9", Width 1.4", Depth 2.3"
Environmental Compliance: Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
