Specifications: Device Support: 2.5” SATA HDD/SSD with thickness of 9.5mm or less
Device Size: Slim laptop optical drive, Thickness: 9.5mm
Internal Interface: Standard SATA interface for HDD/SSD
External Interface: Standard Slim SATA interface to laptop
Material: Aluminum & Plastic
Power: SATA Bus Powered
Dimensions: 128 x 126 x 9.5 mm
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10
Linux OS
HDD/SSD and open slim optical bay
Features: Built-in HQ capacitor for stabilized power to HDD/SSD
4 channels switch, for most brands of Laptop PC
Design with Vibration Dampener and 360 Degree Anti-Shock bumper
Static Electricit...
Specifications: Chipset ID: ASMedia - ASM1092R
Compatible Drive Types (Type and Rate): M.2 (NGFF; B-Key)
Drive Installation: Fixed
Drive Size: 22m - M.2 NGFF
Interface : SATA
Number of Drives: 2
Supported Drive Height(s):
2230
2242
2260
2280
Maximum Data Transfer Rate: 6Gbps
MTBF: 500000
Port Multiplier: Yes
RAID: Yes
Supported RAID Modes:
RAID 0 (Striped Disks)
RAID 1 (Mirrored Disks)
JBOD - (Just a Bunch of Disks)
BIG (Spanning or Concatenation)
Type and Rate: SATA III (6 Gbps)
Drive Connectors: 1 - SATA Data & Power Combo (7+15 pin) Female
Host Connectors: 2 - M.2 (NGFF; B-Key) Male
OS Compatibility: OS independent; No software or drivers required
LED Indicators: 2 - Drive Error
Humidity: 5% ~ 95% RH
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Stora...
Conversion Tray: 2 x SATA Power (15 pin) Receptacle
4 x SATA (7 pin; Data) Receptacle
Mobile Rack Drives Support: 4 x SFF-8482 (29 pin; Data & Power; Internal SAS) Receptacle
Mobile Rack Interface: SATA I/II/III/SAS
Protection Case: Multiple Drives
Compatible Products: 3.5" & 5.25"
Specifications: Drive Installation: Removable
Fan Bearing Type: Sleeve Bearing
Fan: 1 - 70 mm
Key Lock: Yes
Number of Drives: 4
Number of internal 3.5 inch bays: 4
Max Drive Capacity: Currently tested with up to 6TB 7200 RPM hard drives
Maximum Data Transfer Rate: 6 Gbit/s
OS Compatibility: OS independent; No software or drivers required
System and Cable Requirements: Flammability rating: UL94 - V0
LED Indicators:
1 x Power LED
1 x Drive 1 Activity LED
1 x Drive 2 Activity LED
1 ...
Mobile Rack Drives Support: 1 x 2.5" Drive to 3.5" Bay
Compatible Products: 2.5"
Specifications: FORM FACTOR 3.5"-to-2.5" Tool-less Hot-Swap Drive Tray
HOT SWAP : Yes
ACCESSORIES: No (Tool-less)
PRODUCT ENVIRONMENTAL COMPLIANCE: RoHS and REACH compliant, details available upon request
