Specifications: Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
-MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
-MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
-Dell XSP 15/13
-ASUS T303ua/ ZenBook 3
-Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
-Chromebook Pixel 2
-HP EliteBook Folio G1/ Spectre 13 X360
-Huawei Matebook
And more...
Smartphones:
-Huawei Mate 10
-Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
-Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Maximum Power Delivery Support: 60 W
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
Mac OS 10.9 to 10.12
Chrome OS
Cable Jakcet Type: Plastic
Features: Expand the connectivity of your MacBook Pro, MacBook, Chromebook or other USB-C enabled laptop
Power both the multiport adapter and your laptop simultaneously, using your laptop...
Specifications: Converter Type: Format Converter
Maximum Analog Resolutions: 2048 x 1280 @ 60hz
Maximum Digital Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2048 x 1280
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Humidity: 25% to 85% RH Non-Condensing
Operating Temperature: 5 to 35 degree C (41 to 95 degree F)
Storage Temperature: 5 to 35 degree C (41 to 95 degree F)
Output Connector: 1 x VGA (15 pin, High Density D-Sub) Female Output
Dimensions: 0.60" x 1.70" x 7.30"
Weight: 1.00 oz.
Package Contents: 1 x USB-C to VGA video adapter
1 x quick-start guide
Specifications: System Requirements:
USB-C device that supports USB DisplayPort Alternate Mode
DVI-enabled display
Thunderbolt 3: Yes
Output Connector: Side A:
1 x USB C (MALE)
Side B:
1 x DVI-I DUAL-LINK (FEMALE) (WIRED TO DVI-D SINGLE-LINK)
1 x USB 3.0 A (FEMALE)
1 x RJ45 (FEMALE)
1 x USB C (FEMALE)
Weight: 0.15
Package Contents: U444-06N-DGU-C USB 3.1 Gen 1 to DVI DisplayPort Alternate Mode External Video Adapter
Owner’s manual
Specifications: System Requirements:
Computer with USB-C port that supports USB DisplayPort Alternate Mode
DisplayPort, Mini DisplayPort, VGA, DVI or HDMI external display
Ethernet network
Thunderbolt 3: Yes
Package Contents: U442-DOCK1 USB 3.1 Gen 1 USB-C Docking Station
Owner’s manual
Changer Type: Side A - Connector 1
USB-C (Female)
Side B - Connector 1:
3.5mm (Female)
DisplayPort (Female)
VGA (Female)
HDMI (Female)
RJ45 (Female)
2 x USB 3.0 A (Female)
USB-C (Female)
Side B - Connector 2:
3.5mm (Female)
2 x USB 3.0 A (Female)
USB-C (Female)
Color: Silver
Specifications: USB-C docking station with power adds HDMI, VGA, DP, USB, PD Charging and other ports to your Chromebook, MacBook or PC.
Transmits audio/video signals from sources supporting USB DisplayPort Alt Mode
Delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 30 Hz
Connects you to a wired Ethernet network when no Wi-Fi is available
Powers and charges PD Charging-compliant devices, such as MacBooks and Chromebooks
Easy installation with plug-and-play opera...
Specifications: Ports: 2
Side A - Connector 1: USB C (MALE)
Side B - Connector 1: (2) Displayport (FEMALE)
Connector Plating: Nickel
Displayport Specification: 1.4
HDCP Specification: 2.2
USB Specification: USB 3.1 Gen 2 (up to 10 Gbps)
Driver Required: No
MST Support: Yes
Multi-Resolution Support: No
Video Input: USB C (MALE)
Video Output: Displayport (FEMALE)
Number of Monitors Supported: 2
Video Ports: (2) Displayport (FEMALE)
Video Ports Details: HDCP 1.4; HDCP 2.2; DisplayPort 1.4
Supported Resolutions: 1280x720 (720p); 1920x1080 (1080p); 3840x2160 (4K); 7680x4320 (8K)
Max Supported Video Resolution: 7680 x 4320 @ 30 Hz
Audio Ports: (2) Displayport (FEMALE)
Audio Ports Details: Supports pass-through audio function via dual DisplayPort outputs
Audio Input: USB-C
Au...
Specifications: Easy to Add an HDMI Display
USB-A Hub Port
USB-C Port for Charging Portable Devices
System Requirements:
USB-C device that supports USB DisplayPort Alternate Mode
HDMI-enabled display
Thunderbolt 3: Yes
Weight: 0.1
Package Contents: U444-06N-HU-C USB 3.1 Gen 1 USB-C to HDMI DisplayPort Alternate Mode External Video Adapter
Owner’s manual
Specifications: Compatible with Ubuntu 14.04.2
Connector A USB 3.0 A (MALE)
Connector B HD15 (FEMALE)
System Requirements
Compatible with Windows XP, Vista, 7, 8, and 8.1. Supports both 32- and 64-bit.
Supports Surface tablets running non-RT Windows 8 and 8.1
Compatible with Intel Mac OS X 10.8 (10.8.3 and later), 10.9 and 10.10 (Mac OS X 10.9 and 10.10 is limited to a single add-on monitor. See driver Release Notes for details) Supports both 32- and 64-bit.
Mac OS X versions 10.8.5 and earlier do not support audio over USB 3.0. Mac OS X versions 10.7.x and earlier do not support USB 3.0.
Reference the owner's manual for system requirements when using multiple adapters or when using the add-on monitor for DVD playback.
Features: Add an additional VGA monitor through a si...
Specifications: Power Mode: Bus-powered or self-powered
Display: Display resolution: 4K @ 30 Hz / 1080p @ 60 Hz
Ethernet:
Transfer Rate: 1000 Mbps (Half Duplex) / 1000 Mbps (Full Duplex)
IEEE: IEEE 802.3az, IEEE 802.3, 802.3u, and 802.3ab, IEEE 802.3x
Modes:
Supports Wake On LAN function, suspend mode and remote wake-up via link-change, Magic Packet or Microsoft wake-up frame
Supports IEEE 802.1Q VLAN tagging and 2 VLAN ID filtering
Supports Jumbo Frame
Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and TCP Large Send Offload
Output Connector: Host Interface: USB Type-C Male connector
Video Interface: HDMI DB 15 pin Female connector
Ethernet Port: RJ-45 Female connector (Gigabit Ethernet)
USB Port: USB 3.0 Female connector x2
Specifications: Host Interface: USB 3.1 Gen 1 Type-C Male
Video Interface: HDMI Female connector
USB Port: USB 3.0 Female connector
Power Mode: Bus-powered or self-powered
HDMI Display resolution: 3840 X 2160 @ 30 Hz
Housing Material: Plastic
Connector Style: Standard
Weight: Approximately 0.09 lb.
Package Contents: JCA379 USB Type-C HDMI & USB 3.0 with Power Delivery
Quick Installation Guide
