Specifications: 1.Model: WL-UG7501H
2.Chip: DisplayLink DL7400
3.Connection to Host: USB-C/A
4.Video Ports: 4 x HDMI
5.Product Size: 11.3 x 9.9 x 1.5cm/4.5x3.9x0.6in (L x W x H)
6.Cable Length: 23cm/9.1in
7.Product Weight: 206g/7.3oz
Features: - 4 x HDMI ports support quad 4K@60Hz.
- 1 x USB-C/A 2-in-1 cable, easily connect to the host.
- 1 x USB-C 100W PD in charging to the laptop.
Package Quantity: 1
Package Contents: - 1 x Quad 4K@60Hz Universal Display Adapter
- 1 x Quick Start Guide
Specifications: Specification
1.Model: WL-UG7702H-A
2.Ports: Front: 3*HDMI port(4K@60Hz), 1*HDMI port(DP Alt Mode converted to HDMI) (4K@144Hz)
3.Rear: USB-C port(PD IN 140W), USB-C connector(PD pass-through 130W Charging)
4.Unit Size: LxWxH: 11.4x7x1.5 cm/4.5x2.8x0.6 inch
5.USB-C Cable Length: 25.6 cm/10.4 inch
6.Unit Weight: 132g/4.7oz
7.Material: Aluminum Alloy
Features: - Comes with 4*HDMI ports; this display adapter supports 3*4K@60Hz+1*4K@144Hz display output.
- 1 x PD port supports PD pass-through, power in 140W (PD3.1), and charges the laptop at 130W max.
- 1 x USB 3.2 Gen2 (10G) port and a strong, powerful GPU ensure stable video transmission.
- Video display using the SiliconMotion chip solution supports laptops including Thunderbolt 4/3, USB 3.1/3.0, and legacy USB-A port laptops.
Specifications: Host Interface: USB 3.0 male Type-A Connector, Video & Audio Interface: HDMI Female Connector, Power Mode: Bus-powered, Power Consumption: = 300mA
Output Connector: HDMI
Connector Style: Standard
Features: • Easily add an additional display through the USB™ 3.0 and HDMI™ connection • Video playback performs at 1080p HD with a resolution up to 2048x1152 • Add an additional monitor without adding an expensive, internal video card and avoid complicated installation. • Hot-swappable USB™ enables you to add or remove monitors without rebooting your system • Move and view your large documents across two screens without overlapping windows • Multitask with larger landscape/desktop space • Ideal for viewing multiple windows at the same time • ...
Specifications: Chipset: VL100+PS171+PS8348B+IT6516+IT6561
Supports DisplayPort 1.2, 1.62 Gbps, 2.7 Gbps, 5.4 Gbps link rates
Resolution:
DisplayPort: Up to 3840x2160@60Hz
HDMI: Up to 3840x2160@30Hz
DVI: Up to 1920x1080@60Hz
VGA: Up to 1920x1080@60Hz
Note: Supports one connected display at a time
Output Connector: 1 x 20-pin DisplayPort, Female, Output
1 x 19-pin HDMI, Female, Output
1 x 25-pin DVI-D, Female, Output
1 x 15-pin D-Sub VGA, Female, Output
Features: • Supports 4 display modes: Extended, Primary, Mirror, and Rotation Mode. *Functions limited by operating system • Increase productivity: Multitask with a larger landscape/desktop space. Move and view your large spreadsheets across four screens without overlapping windows. Ideal for viewing multiple windows at the same time to enhance productivity from standard business applications. • 1080P HDMI™ resolution with stereo audio: 1920 x 1080 @ 60 Hz, with 1080P Video Playback; display rotation: 0°, 90°, 180°, 270°. 4 HDMI™ ports simultaneously support 48 kHz imbedded audio. • No external power required: USB™ powered with SuperSpeed USB™ 3.0, 5 Gbps • Multitask effectively: Great for multitasking in a wide variety of applications including phone ce...
Specifications: Easy to Add an HDMI Display
USB-A Hub Port
USB-C Port for Charging Portable Devices
System Requirements:
USB-C device that supports USB DisplayPort Alternate Mode
HDMI-enabled display
Thunderbolt 3: Yes
Weight: 0.1
Package Contents: U444-06N-HU-C USB 3.1 Gen 1 USB-C to HDMI DisplayPort Alternate Mode External Video Adapter
Owner’s manual
Type: USB 3.1 Type C to HDMI 2.0 UHD 4K 60HZ Active Adapter
Color: Black
Specifications: Supports up to 4K UHD Resolution at 60Hz.
The USB 3.1 Type C to HDMI 2.0 UHD 4K 60Hz Active Adapter supports UHD resolutions of up to 4K @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video. Use the adapter to play games, view video or browse the internet from your USB 3.1 Type-C enabled device on a (Ultra) high-resolution monitor or TV. Supporting up to 8 channels of audio, the adapter provides high-definition digital audio and video.
Compatible with all Operating Systems
The USB 3.1 Type C to HDMI 2.0 UHD 4K 60Hz Active Adapter supports all USB 3.1 Type-C devices with DisplayPort ALT mode and operating systems, including Apple OS X, Windows 8.1 and 10 and Google Chrome OS...
Changer Type: USB-C to HDMI / RJ45 / USB 3.0 / USB-C
Color: Black
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: VIA/VLI - VL102, VIA/VLI - VL817, Parade Technologies - PS176, RealTek - RTL8153
Displays Supported: 1
Fast-Charge Port(s): Yes
Power Delivery: 100W
Power Source:USB-Powered
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Full Duplex Support: Yes
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions:
4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
UltraWide - 3440 x 1440p @ 60 Hz or 2560x1080 at 60Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p.
Type and Rate: U...
Specifications: USB-C to VGA cord connects your VGA display to the USB-C or Thunderbolt 3 port on your laptop, MacBook or Chromebook.
Transmits video signals from sources supporting USB DisplayPort Alt Mode
Delivers HD picture quality at resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 speeds up to 5 Gbps to ensure fast data transfers
Reversible USB-C plug connects in either direction for immediate no-fuss use
Easy installation with plug-and-play operation-no software required
Connector:
Side A - Connector 1: USB-C (MALE)
Side B - Connector 1: VGA (FEMALE)
Thunderbolt 3: Yes
Features: Connects a VGA Display to Your USB-C or Thunderbolt 3 Device
This USB 3.1 to VGA adapter helps you transmit video from your tablet, laptop, Chromebook, ...
Specifications: Supports USB DisplayPort Alternate Mode for Transmitting Video
Reversible USB-C plug connects your device to an existing DVI display, saving you the time, money and effort of additional adapters and cables
Extend video to a second monitor, duplicate the same video on both monitors, or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Plug and play with no external power supply or drivers required
Compatible with USB-C devices that support USB DisplayPort Alternate Mode
Vibrant, Superior Video Quality
Supports HD video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Supports USB 3.1 Gen 1 data transfer rates up to 5 Gbps
Supports DVI digital transfer rates of 6.75 Gbp...
Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0) / 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 3840 x 2160p (HDMI)
Type and Rate USB: 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.9 to 10.12 / Chrome OS
Power Source: USB-Powered
Output Connector: 1 x USB Type-C (24 pin) USB 3.0 Male
1 x HDMI (19 pin) Female
1 x RJ-45 Female
2 x USB Type-A (9 pin) USB 3.0 Female
1 x USB Type-C (24 pin) USB 3.0 Female
Features: Expands the connectivity of your port-limited laptop, using the convenient built-in USB-C cable
Power both the multifunctio...
