Distance: Maximum Distances - (1080i only)
CAT5E (stranded) - 40m (130 ft.)
CAT5E (solid) - 50m (165 ft.)
CAT6 (stranded or solid) - 50m (165 ft.)
Max Distance: 50m / 165 ft.
Resolution Support: Maximum Digital Resolutions: 1080p / 1920x1080
Supported Resolutions:
1080i
- Cat6 (stranded or solid) - up to 50m
- Cat5e (solid) - up to 50m
- Cat5e (stranded) - up to 40m
1080p
- Cat6 (solid or stranded) - up to 40m
- Cat5 (solid) - up to 20m
- Cat5 (stranded) - up to 16m
See product manual for further details
HDMI: Local Unit Connectors:
1 x HDMI (19-pin) Female
Remote Unit Connectors:
1 x HDMI (19-pin) Female
Network Interface: Local Unit Connectors:
2 x RJ-45 Female
Remote Unit Connectors:
2 x RJ-45 Female
Network Interface: USER INTERFACE:
Indicator LEDs: Outputs, inputs, communication link and power
Controls: EDID setup button, 12 setup DIP switches
1 RS-232: On a Mini–USB female connector for firmware upgrade
S-Video: VIDEO:
Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
Max. Resolution: Up to 4K@60Hz (4:2:0) 24bpp
Standards Compliance: Supports HDCP 1.4 and HDBaseT 1.0
HDMI Support: Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
Other Connector: INPUTS:
1 HDMI: On an HDMI female connector
OUTPUTS:
2 HDBT: On RJ–45 female connectors
1 Loop HDMI: On an HDMI female connector
PORTS:
1 IR: On a 3.5mm mini jack for IR link extension
1 RS-232: On a 3–pin terminal ...
Specification: Hardware
Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: No
Output Signal: HDMI
Ports: 1
Rack-Mountable: Yes
Performance
Audio Specifications: 7.1 Surround Sound
Max Distance: 70 m / 230 ft
Maximum Cable Length: 0.2 ft [0.1 m]
Maximum Digital Resolutions: 4096 x 2160 (4K) @ 30 Hz
Wide Screen Supported: Yes
Connector(s)
Connector A:
- 1 x HDMI (19 pin) Female Input
- 1 x RJ-45 Female Output
Connector B:
- 1 x HDMI (19 pin) Female Output
- 1 x RJ-45 Female Input
Local Unit Connectors:
- 1 x HDMI (19 pin) Latching Female Input
- 1 x RJ-45 Female Output
Remote Unit Connectors:
- 1 x HDMI (19 pin) Female Output
- 1 x RJ-45 Female Input
Indicators
LED Indicators: 1 x Status LED (receiver)
Power
Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 ~ 240 AC
Output Current: 1.5 A
Output Voltage: 12 DC
Plug Type: M
Powe...
Resolution Support: 480p/720p/1080p at 60 Hz; 1920 x 1200 and 1600 x 1200 at 60 Hz
Video Bit Rate/Bandwidth: 340 MHz (10.2 Gbps)
Power Consumption: 20W
Power Supply: AC input: 100-240 VAC, 50-60 Hz, 0.8 A
Output: 5-VDC, 2 A
Specification: Audio Support: Stereo 2-channel analog audio
RoHS: Yes
Connectors: Transmitter: 1 x DVI-D F input, 1 x DB9 F (RS-232), 1 x 3.5-mm input jack (stereo audio), 1 x RJ-45 (CATx interconnect)
Receiver: 1 x DVI-D F output, 1 x DB9 M (RS-232), 1 x 3.5-mm output jack (stereo audio), 1 x RJ-45 (CATx interconnect)
Indicators: 2 x LEDS on both the transmitter and receiver: 1 x Power, 1 x Link
Feature: Use a single CAT5e/6/7 run for extending DVI-D video plus audio.
Also extends RS-232 and HDCP signals to the remote screen.
Goes much farther than standa...
Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
System Requirements: Computer with DVI video card, and monitor with DVI input
Specification: Cable Type: DVI
Display Style: Extender
Connector A: DVI-D SINGLE LINK (MALE)
Connector B: X2) RJ45 (FEMALE)
Connector C: DVI-I (FEMALE)
Power Supply: Input: 100-240V, 50/60Hz, 0.5A
Output: 5V, 2A
Specification: Connector A:3 x HD15 (FEMALE)
Connector B:2 x RJ45 (FEMALE)
Maximum Operating Distance:1000 ft
Number of Output Devices Supported:2
Number of Input Devices Supported:1
Twisted Pair Cable Standard:Category 6
Media Type Supported:Twisted Pair
Feature: Extends a 1920 x 1440 (60Hz) video signal up to 500 ft., or a 1024 x 768 (60Hz) video signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6)
EDID copy feature ensures optimal display compatibility
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K
The remote (Receiver) unit features built-in Equalizatio...
Resolution Support: Maximum Digital Resolutions: 3840 x 2160 (4K) @ 60 Hz
Supported Resolutions:
3840 x 2160 (4K) 60 Hz
2560 x 1600 60 Hz
1920 x 1200 60 Hz
1920 x 1080 (1080p) 60 Hz
1280 x 720 (720p) 60 Hz
* Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Audio: 7.1 Surround Sound
HDMI: Connector A: 1 x HDMI (19-pin) Female
Connector B: 1 x HDMI (19-pin) Female
Network Interface: Connector A: 1 x RJ-45 Female
Connector B: 1 x RJ-45 Female
Power Supply: Center Tip Polarity: Positive
Input Current: 0.3A
Input Voltage: 110-240V AC
Output Current: 1A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
Specification: Hardware
Audio: Yes
AV Input: HDMI
AV Output: HDMI
Cabling: Cat 6 UTP
Performance
Maximum Cable Length: 165 ft.
Wid...
Extender & Repeater Type: Video Extender Transmitter/Receiver
Package Content: 1 x Wireless Transmitter
1 x Wireless Receiver
1 x IR Blaster
1 x IR Receiver
4 x Wireless Antenna
2 x Universal Power Adapter (NA/EU/UK)
2 x Mounting Kit
1 x Set of Rubber Feet
1 x Quick-Start Guide
