Power Supply: Input: 100-240V, 50/60Hz, 0.5A
Output: 5V, 2A
Specification: Connector A:3 x HD15 (FEMALE)
Connector B:2 x RJ45 (FEMALE)
Maximum Operating Distance:1000 ft
Number of Output Devices Supported:2
Number of Input Devices Supported:1
Twisted Pair Cable Standard:Category 6
Media Type Supported:Twisted Pair
Feature: Extends a 1920 x 1440 (60Hz) video signal up to 500 ft., or a 1024 x 768 (60Hz) video signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6)
EDID copy feature ensures optimal display compatibility
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K
The remote (Receiver) unit features built-in Equalizatio...
Frequency Band Range: IR Emitter & Receiver: 38kHz, 47kHz & 56kHz
Resolution Support: 640 x 480 to 4K@30Hz
Video: Video Streaming Approx. 70ms Latency
Audio: Audio Output: PCM Stereo
USB Port: Transmitter: 1 x USB HID Input (for Mouse & Keyboard); Receiver: 2 x USB Input (for Mouse & Keyboard)
S-Video: Video Input Transmitter: 1 x HDMI Input; Receiver: 1 x HDMI Output
Video Output Transmitter: 1 x HDMI Output (Local Pass-through); Receiver: 1 x HDMI Output
Distance: Maximum Distances - (1080i only)
CAT5E (stranded) - 40m (130 ft.)
CAT5E (solid) - 50m (165 ft.)
CAT6 (stranded or solid) - 50m (165 ft.)
Max Distance: 50m / 165 ft.
Resolution Support: Maximum Digital Resolutions: 1080p / 1920x1080
Supported Resolutions:
1080i
- Cat6 (stranded or solid) - up to 50m
- Cat5e (solid) - up to 50m
- Cat5e (stranded) - up to 40m
1080p
- Cat6 (solid or stranded) - up to 40m
- Cat5 (solid) - up to 20m
- Cat5 (stranded) - up to 16m
See product manual for further details
HDMI: Local Unit Connectors:
1 x HDMI (19-pin) Female
Remote Unit Connectors:
1 x HDMI (19-pin) Female
Network Interface: Local Unit Connectors:
2 x RJ-45 Female
Remote Unit Connectors:
2 x RJ-45 Female
Other Connector: Local Unit Connectors
1 - HDMI
1 - HDMI
1 - RJ-45
1 - Barrel Power Connector (Size M, OD:5.50, ID: 2.10)
1 - 3.5mm Stereo Female 3 pos
Remote Unit Connectors
1 - HDMI
1 - 3.5mm Stereo Female 3 pos
1 - Toslink (SPDIF, Optical)
1 - Barrel Power Connector (Size M, OD:5.50, ID: 2.10)
1 - RJ-45
Software Application: Software:
OS Compatibility
No Drivers or Software Required
LED Indicator: 1 - Flashing Blue: Power connected, but no HDMI input signal is detected
Solid Blue: Power connected, and a HDMI input signal is detected
Power Consumption: 0.1W
Power Supply: Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
0.3A
Output Voltage
12V DC
Output C...
Resolution Support: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a);
1080p@100m
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60 Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30 Hz (4:4:4)
Video: Video
Max. Data Rate: 10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock: Up to 340 MHz
Compliance:
HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
HDMI: VE812T
Input Interfaces: 1 x HDMI Type A Female (Black)
VE812R
Output Interfaces: 1 x HDMI Type A Female (Black)
Power Consumption: VE812R: 5.3 VDC, 4.5W
VE812T: 5.3 VDC, 1.9W
Distance: Max Distance: 70m (230 ft.)
Maximum 1080p Distance: 70m (230 ft.)
Maximum 4K Distance: 35m (115 ft.)
Resolution Support: 4K x 2K (Ultra HD) @ 30 Hz
2560 x 1600 @ 60 Hz
1920 x 1200
1920 x 1080 (1080p)
1280 x 720 (720p)
Power Consumption: 64.8W
Power Supply: Center Tip Polarity: Positive
Input Current: 1.5A
Input Voltage: 100 ~ 240 AC
Output Current: 2.7A
Output Voltage: 24 DC
Plug Type: 4-pin DIN
Power Source: AC Adapter Included
Specification: Hardware
Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: Yes
Output Signal: HDMI
Ports: 4
Rack-Mountable: Yes
Performance
Maximum Cable Length: 2755.9 in [70000 mm]
Maximum Digital Resolutions:
- 4096 x 2160 (4K) @ 30 Hz - maximum distance 35m (115 ft.)
- 1920 x 1080 (1080p) - maximum distance 70m (230 ft.)
Special Notes / Requirements
Note: CAT6 STP Cables provide protect...
System Requirements: Resolution may vary at distances depending on cable quality. Cat 5e UTP cables are recommended.
Power Supply: Power Adapter Included: Yes
Output Voltage: 12 DC
Output Current: 0.6A
Center Tip Polarity: Positive
Specification: Cabling: Cat 5 UTP
Audio: No
Daisy-Chain: No
Color: Black
Enclosure Type: Aluminum
Local Unit Connectors
1 - RJ-45 Female
1 - VGA (15 pin; High Density D-Sub) Female
Remote Unit Connectors
1 - RJ-45 Female
1 - VGA (15 pin; High Density D-Sub) Female
Feature: Extends video signal by up to 250 ft. (80m)
Supports 1920x1200 or 1600x1200 resolutions at 150 ft. (50m)
Supports 1280x1024 or 1024x768 resolutions at 2...
Feature: Extends HDMI signals with stereo audio to a remote display over UTP CAT5e/6 cabling up to 120 meters
Works as a scalable TX/RX Matrix over dedicated IP network, allows up to 256 total units, limited to 100 transmitters. Additional transmitter units (part# CE-H23B11-S2) and receiver units (part# CE-H23C11-S2) sold separately
Supports up to 1080p @60Hz video resolution to deliver stunning and crystal clear images
Supports IR pass back function to control the source device from RX location
Supports computer control software to select and switch between source devices (Matrix only)
Supports HDbit-T protocol with H.264 compression over IP
HDMI output on the transmitte...
Other Connector: Connector B: 3.5MM (FEMALE)
Connector C: RJ45 (FEMALE)
Specification: Color: Black
Feature: Works with a B132-002A or B132-004A local unit to extend a 1920 x 1440 (60Hz) Video and Audio signal up to 500 ft., or a 1024 x 768 (60Hz) Video and Audio signal up to 1,000 ft.
24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6), is required to achieve maximum distance and resolution
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K
Features built-in Equalization and Gain controls to adjust the video image
Includes mounting hardware that allows unit to be wallmounted, rackmounted or pole mounted
Ideal for digital signage situations...
Other Connector: Connector A
1 - HDMI (19 pin) Female Input
1 - USB B (4 pin) Female
1 - RJ-45 Female
Connector B
1 - HDMI (19 pin) Female Output
4 - USB A (4 pin) Female
1 - RJ-45 Female
LED Indicator: 1 - Link OK / POWER - Transmitter
1 - Reset - Transmitter
1 - Link OK / POWER - Receiver
1 - Reset - Receiver
Power Supply: Center Tip Polarity: Positive
Input Current: 0.6 A
Input Voltage: 100 ~ 240 AC
Output Current: 1.5 A
Output Voltage: 12 DC
Plug Type: M
Power Source: AC Adapter Included
